Details Tech Specs Size Chart Warranty Designed for mastering the backstreets of the urban jungle, the Back Alley is a fixed gear single speed steel bike made with equal parts artistry and attitude. It features flat bars and puts the rider in a more uprigh
Designed for mastering the backstreets of the urban jungle, the Back Alley is a fixed gear single speed steel bike made with equal parts artistry and attitude. It features flat bars and puts the rider in a more upright riding position to spot and dodge obstacles ahead. The Back Alley boasts riser handlebars for wheelies and bunny hopping off curbs, BMX-style grips, a steel frame, steel tubular fork, and fixed free capabilities (to run as a single speed or fixed gear), as well as removable brake hardware/cable guides for a clean look. The Back Alley was inspired by Nelson Vailsthe first African-American cyclist to win an Olympic Medal in cycling. Created by Raleigh in collaboration with Nelson and his best friend, famous graffiti artist, Zephyr, the Back Alleys story actually takes place before Nelsons Olympic days when he rode fixed gear bikes as a messenger in NYC. The frame features meaningful original illustrations by Zephyr including Nelsons signature Converse Chuck Taylor Hi Tops, an iconic dime (what Nelson used to call his messenger service for the location of his next job), the flag of the Checkered Cab (onto which Nelson grabbed bumpers to catch rides), the notorious TOGA bike shop (where messengers hung out), and Cats Paw Hill in Central Park (where the crew met to ride and skate), among others
| Frame: | Hi-Ten Steel With Removable Cable Guides |
|---|---|
| Fork: | Hi-Ten Steel With Die-Cast Drop Outs |
| Crank: | 170mm Alloy Track (Large and X-Large = 175mm) |
| Hubs: | Alloy High Flange, 32 hole |
| Headset: | Sealed 1-1/8″ |
| Wheelset: | Alloy, 40mm High Profile |
| Seatpost: | Alloy Micro Ajust, 27.2 x 350mm |
| Bottom Bracket: | Sealed Cartridge |
| Chain: | KMC Z410 |
| Stem: | Alloy, 31.8, 7 Deg Rise, 105mm Extension (90mm for Small) |
|---|---|
| Handlebars: | Alloy, 31.8mm Clamp Diameter, 620mm Wide, 45mm Rise, 6 Deg Backsweep, 6 Deg Upsweep |
| Saddle: | Raleigh Classic Road |
| Sprocket: | 42 Tooth |
| Cogset: | 16 Tooth Freewheel, 16 Tooth Fixed |
| Brakes: | Alloy Dual Pivot Caliper |
| Pedals: | PC Platform |
| Tires: | Kenda 193, 700x32c |
| Hubs: | Alloy High Flange, Fixed / Free (Rear Flip-Flop), 32 hole |
All bikes purchased through City Grounds MUST be assembled by a certified bike shop mechanic. If the bike is NOT built by a certified bike shop mechanic, any warranty will be VOID. We will request for an assembly receipt as proof of professional installation.
Forallwarranty claims, please contact our Warranty Team [email protected]. So that we can help you in a timely manner, make sure to include the following:
We evaluate all warranties case-by-case to determine the best course of action and get you serviced to the best of our ability!
Warranty doesnotapply to the following:
Labor and shipping are the responsibility of the customer. We do not cover parts purchased and labor performed by another bike shop.
Note: Warranty is for original owner only.
