Name: 2025 Orbea Terra H30 Artichoke/Lilac
SKU: DDV9029085902
Availability: InStock

Key Features

Orbea Terra Hydro disc frame, featuring hydroformed triple-butted aluminum for low weight and high durability.
Full carbon Orbea Terra ICR fork with internal cable routing for stiffness and vibration damping.
Performance-oriented Shimano GRX RX610 2×12-speed drivetrain with a 30x46t crankset and 11-36t cassette.
Powerful and reliable Shimano RX400 Hydraulic Disc Brakes.
Fast-rolling Vittoria Terreno Dry Gravel 700x38c tires, perfect for mixed terrain.
Comfort-focused SP 0.2 Carbon seatpost with 27.2mm diameter.
Includes the MMS (Multiple Mounts System) for maximum cargo versatility.
Ergonomic OC Gravel GR31-R handlebar designed for control and comfort on long gravel rides.

Full Specifications

Frame	Orbea Terra Hydro disc, hydroformed triple butted aluminium, HS 1.5″, PF, Thru Axle 12mm x 142mm rear, DT internal cable routing, 27.2mm seat tube, MMS system
Fork	Orbea Terra ICR, full carbon, 1-1/8″ – 1.5″ tappered head tube compatible, Thru axle 12x100mm
Headset	FSA 1-1/2″ Integrated Aluminium Cup
Handlebar	OC Gravel GR31-R, Rise 15, Reach 70, Drop 110
Stem	OC Road Performance RP22, -5
Handlebar Tape	Orbea Eva
Brakes	Shimano RX400 Hydraulic disc
Rotors	(Not Specified)
Drivetrain	2x
Shifters	Shimano GRX RX610
Rear Derailleur	Shimano GRX RX820
Front Derailleur	Shimano GRX RX820
Crankset	Shimano GRX RX610 30x46t
Bottom Bracket	PF (PressFit, assumed)
Chain	Shimano M6100
Cassette	Shimano HG710 11-36t 12-Speed
Wheels	Alloy, Tubeless, 700c, 21c inner width
Front Wheel Axle	Orbea Thru Axle 12x100mm M12x2 P1 Solid
Rear Wheel Axle	Orbea Thru Axle 12x142mm M12x2 P1 Solid inner threaded
Tires	Vittoria Terreno Dry Gravel 700x38c
Saddle	Prologo Akero AGX black rails, size 155mm
Seatpost	SP 0.2 Carbon, 27.2mm, Setback 20mm
Rear Dropout / Hub Dimensions	12mm x 142mm

Geometry

	XS	S	M	L	XL	XXL
Seat Tube (C-T)	425mm	458mm	491mm	524mm	557mm	590mm
Top Tube (EFF)	526mm	539mm	558mm	570mm	590mm	603mm
Head Tube	110mm	131mm	152mm	178mm	199mm	220mm
Chainstay	430mm	430mm	430mm	430mm	430mm	430mm
BB Drop	78mm	78mm	78mm	76mm	76mm	76mm
BB Height	263/278mm	263/278mm	263/278mm	265/280mm	265/280mm	265/280mm
Wheelbase	1020mm	1030mm	1039mm	1054mm	1063mm	1072mm
Head Angle	70.0	70.5	71.0	71.0	71.5	72.0
Seat Angle	74.0	74.0	73.5	73.5	73.0	73.0
Rake	–	–	–	–	–	–
