Key FeaturesTrifecta V2 High Pivot Suspension: 160mm of rear travel via an inverted four-bar linkage, delivering exceptional stability and big-hit performance for Enduro/Bike Park use.SRAM X0 Eagle Transmission (T-Type): Top-tier electronic wireless shifti
| Product | Forbidden Dreadnought 1 Bike |
|---|---|
| Model Year | 2025 |
| Intended Use | Enduro / All-Mountain / Freeride / Bike Park |
| Rider | Unisex |
| Sizes and Geometry | S1, S2, S3, S4 (29″ and MX) |
| Wheel Size | 29″ or Mixed (29″ Front / 27.5″ Rear) |
| Frame Material | Carbon Fiber |
| Frame Material Details | High-modulus carbon fiber front and rear triangles, forged V2 Rate Control Linkage, molded protection, integrated rear fender |
| Rear Travel | 160mm |
| Rear Shock | RockShox Vivid Ultimate, Touchdown RC2T damper, 205mm x 60mm |
| Fork | RockShox ZEB Ultimate, Charger 3.1 RC2 damper, 44mm offset, 38mm stanchions |
| Fork Travel | 170mm |
| Head Tube Diameter | Tapered, 1.125″ top, 1.5″ bottom |
| Headset | Cane Creek Hellbender 70, ZS44/28.6 upper, ZS56/40 lower |
| Handlebar | Burgtec Ride Wide Enduro Carbon, 800mm width, 35mm clamp Rise: 22.5mm (S1/S2), 30mm (S3/S4) |
| Stem | Burgtec MK3 Enduro, 42.5mm length, 35mm bar clamp |
| Grips | Forbidden, single clamp lock-on, 128mm length |
| Brakes | SRAM Maven Ultimate, 4-piston, organic pads Rotors: SRAM HS2, 6-bolt, 200mm |
| Brake Levers | SRAM Maven Ultimate Stealth, tool-free reach and contact point adjust |
| Drivetrain | 1x |
| Shifters | SRAM Eagle Pod Rocker Controller, 12-speed, AXS electronic wireless |
| Front Derailleur | None |
| Rear Derailleur | SRAM X0 Eagle Transmission, 12-speed, AXS electronic wireless |
| ISCG Tabs | ISCG05, lower two bolts only |
| Chainguide | Forbidden Race upper idler pulley guide, MRP MXg lower pulley with bashguard |
| Cranks | SRAM X0 Eagle Transmission Alloy DUB, 165mm length |
| Chainrings | SRAM X0 Eagle Transmission, 32 tooth |
| Bottom Bracket | SRAM DUB Wide, 73mm English/BSA threaded |
| Pedals | None |
| Chain | SRAM X0 Eagle Transmission Flattop, 12-speed |
| Cassette | SRAM X0 Eagle Transmission XS-1295, 12-speed, 10-52 tooth |
| Rims | Crankbrothers Synthesis 11 Carbon, tubeless ready Front: 31.5mm inner; Rear: 29.5mm inner |
| Hubs | Crankbrothers, 15x110mm Boost front, 12x148mm Boost rear with Ratchet freehub and XD driver |
| Spokes | Sapim CX Ray (F) / Sapim CX Sprint (R), stainless steel, bladed |
| Tires | Front: Maxxis Assegai, 3C MaxxTerra, EXO, TR, 29″ x 2.5″ Rear: Maxxis Forekaster, 3C MaxxTerra, EXO+, TR, 2.4″ |
| Saddle | fi’zi:k Terra Alpaca X5, S-Alloy rails, 145mm width |
| Seatpost | OneUp dropper Drop: 120mm (S1), 150mm (S2), 180mm (S3), 210mm (S4) |
| Seatpost Diameter | 31.6mm |
| Seatpost Clamp | Forbidden, 7075 CNC anodized aluminum, 34.9mm |
| Rear Dropout / Hub Dimensions | 12mm x 148mm (Boost) |
| Max. Tire Size | 2.5″ |
| Bottle Cage Mounts | One inside front triangle, plus accessory mounts under top tube |
| Colors | KX500, Arrakis |
| Warranty | Lifetime frame |
| Weight | |
| Miscellaneous |
|
Figures are based on stock **0mm offset** dropouts and a 170mm fork (586mm A-C, 44mm offset). Values are listed as: **29″ Geometry** / **Mixed (MX) Geometry**. All measurements are in millimeters (mm) unless otherwise noted.
| Size | S1 | S2 | S3 | S4 |
|---|---|---|---|---|
| Reach | 435 / 430 | 455 / 450 | 475 / 471 | 495 / 491 |
| Stack | 615 / 618 | 628 / 632 | 642 / 645 | 655 / 659 |
| Top Tube Length (Effective) | 571 / 572 | 594 / 595 | 617 / 618 | 640 / 641 |
| Head Tube Angle | 63.5 / 63.1 | 63.5 / 63.1 | 63.5 / 63.1 | 63.5 / 63.1 |
| Seat Tube Angle (Effective) | 77.5 / 77.1 | 77.5 / 77.1 | 77.5 / 77.1 | 77.5 / 77.1 |
| Chainstay Length (Rear Center) | 431 | 446 | 460 | 475 |
| Wheelbase | 1206.5 / 1206.5 | 1247.7 / 1247.6 | 1288.9 / 1288.8 | 1330.1 / 1330.0 |
| Standover | 771 | 775 | 777 | 780 |
| Bottom Bracket Height | 347 / 341 | 347 / 341 | 347 / 341 | 347 / 341 |
| Head Tube Length | 90 | 105 | 120 | 135 |
| Recommended Fork Offset | 44mm | 44mm | 44mm | 44mm |
| Additional Info |
|
